One sheet Combat Foamie

Discussion in 'Single Wing Aircraft Plans' started by mb3987, Dec 6, 2012.

  1. mb3987

    mb3987 New Member

    Offline
    Messages:
    16
    Trophy Points:
    1
    Not my original design but got permission to post files.

    First project for sketchup and g-code for me. The guys in our club really like.
    In the video our club "Foam master" built a version without battery protectors.

    Added cut out for servo.

    Elevons cut 3/4" from edge. Cut with razor knife rather than machine to keep it tight.

    Attached files [​IMG] Combat_Foamie.cnc (19.3 KB)Â Combat_Foamie.pdf (445 KB)Â [​IMG] [​IMG]

  2. mb3987

    mb3987 New Member

    Offline
    Messages:
    16
    Trophy Points:
    1
    Want to give credit where credit is due.

    I should have included a link to Paul Bradleys web site. He is the one who drew this up.
    Jerry Hagood was the designer.

    http://www.parmodels.com/

    Mike

  3. kram242

    kram242 Administrator Staff Member

    Offline
    Messages:
    6,311
    Trophy Points:
    13
    Location:
    NJ
    Good deal Mike thanks for the update
    Mark and Trish
